Description
Seamlessly integrating into kitchen cabinetry, with quiet performance and flexible loading. Auto door open at the end of the cycle releases steam, while AirCurtain technology helps protect surrounding cabinetry.
Features
FLEXIBILITY FOR EVERYDAY USE (16 PLACE SETTINGS)
Accommodates 16 place settings with flexible solutions including a third rack, adjustable middle rack, and a combination of pitch-adjustable and foldable tines. An external indicator light signals cycle completion, so you know exactly when it’s ready to unload.
INTELLIGENT CARE FOR EVERY LOAD (7 CYCLES)
Seven wash programs, including Auto, adapt to the needs of each load for consistently effortless results. The Sanitize modifier provides extra protection by eliminating 99.9% of bacteria*, giving greater confidence when caring for everyday items. *Certified to NSF/ANSI Standard
EFFORTLESS DRYING WITH AIRCUTAIN
At the end of the cycle, the door automatically opens to release excess steam, while innovative AirCurtain technology creates a protective barrier, helping to safeguard surrounding cabinetry over time. Combined with the Dry+ modifier, this ensures effective drying with reduced energy use.
DESIGNED TO MINIMIZE IMPACT
Recognized as Energy Star Most Efficient, this dishwasher is designed to help reduce water and energy use by minimizing resource consumption. It supports a lower household footprint while delivering consistent, high performance.
CONNECTED FOR EVERYDAY EASE (SMARTHQ™)
Introducing the SmartHQ™ App - Now you’re in control, wherever and whenever. Get the most out of your Wi-Fi enabled appliance with Smart HQ making it easy to connect, control and monitor your smart dishwasher anywhere. You can conveniently access the latest tips, remote status notifications and more.
Specifications
General
Series Name
Series 7
Type
Built-In
Color
Panel Ready
Manufacturer Color
Panel Ready
Place Settings
16
Silence Rating
44 dB
Cycle Information
Number of Cycles
7
Wash Cycles
• 60 min
• Auto
• Eco
• Heavy
• Light
• Medium
• Rinse
• Auto
• Eco
• Heavy
• Light
• Medium
• Rinse
Options
Dry +
Half load
Sanitise
Wash modifiers: 3
Half load
Sanitise
Wash modifiers: 3
Features
Technologies
SmartHQ™ App
Filtration System
Yes
Silverware Basket
Yes
Wi-Fi
Yes
Additional Information
• Water usage (per wash cycle) 3.2 g
• Accommodates round plates up to (lower basket): 12 3/4"
• Accommodates round plates up to (top basket): 8 10/16"
• Adjustable height, foldable cupracks
• Easy lift adjustable upper basket
• Fold down tines
• Fold down wine racks
• Full width cutlery/utensil tray
• Pitch adjustable tines
• Wine glass supports
• Energy saving delay start option of up to 24 hours
• Floor light cycle feedback
• Internal wash selector
• Keylock
• Rinse aid indicator light
• Air curtain for bench protection
• Auto Door Open Dry
• Flood protection
• Half load option
• Internal tub material: Stainless Steel
• Motor type: BLDC
• ThermoDry system
• Three-stage filtration system
• Accommodates round plates up to (top basket): 8 10/16"
• Adjustable height, foldable cupracks
• Easy lift adjustable upper basket
• Fold down tines
• Fold down wine racks
• Full width cutlery/utensil tray
• Pitch adjustable tines
• Wine glass supports
• Energy saving delay start option of up to 24 hours
• Floor light cycle feedback
• Internal wash selector
• Keylock
• Rinse aid indicator light
• Air curtain for bench protection
• Auto Door Open Dry
• Flood protection
• Half load option
• Internal tub material: Stainless Steel
• Motor type: BLDC
• ThermoDry system
• Three-stage filtration system
Electrical Information
Information
• 100-120 V
• 60 Hz
• 10 A
• Energy usage: 210kWh/year
• 60 Hz
• 10 A
• Energy usage: 210kWh/year
Accessories
Optional
• Handle kit Professional round flush, Brass off-stands: AHP3DDDW24BA
• Handle kit Professional round flush, Dark Copper off-stands: AHP3DDDW24DC
• Handle kit Professional round flush, Dark Copper off-stands: AHP3DDDW24DC
Dimensions
Class Width
24"
Width
23.5 inch(es) / 59.69 cm
Height (Min.)
33.75 inch(es) / 85.73 cm
Depth (Without Handle)
22.62 inch(es) / 57.46 cm
